MOWER DECK
7-50 GT Series Tractors Service Manual
7
Mower Deck Pulley Installation
1. Slide the pulley and the spacer onto the spindle
shaft (54” mower spindle shown) (Fig. 911).
Fig 911 PICT-7880
Fig 912 PICT-7879
If the mower deck, spindle covers and mower deck belt
have to been removed:
Install the mower deck belt onto the mower deck. Refer
to:
´0RZHU'HFN%HOW,QVWDOODWLRQRQSDJH
´0RZHU'HFN%HOW,QVWDOODWLRQRQSDJH
Install the mower deck onto the tractor. Refer to:
´0RZHU'HFN,QVWDOODWLRQRQSDJH
´0RZHU'HFN,QVWDOODWLRQRQSDJH
2. Block the blade and install a nut onto the spindle
shaft (Fig. 912).
