MOWER DECK
7-1GT Series Tractors Service Manual
7
50” Mower Deck Belt Replacement
50” Mower Deck Belt Removal
1. Remove the mower deck from the tractor. Refer to
“50” Mower Deck Removal” on page 7-6.
2. Remove the 3 screws securing the left hand spindle
cover to the mower deck (Fig. 743).
4. Remove the 4 screws securing the right hand
spindle cover to the mower deck (Fig. 000).
Note: There is a hook retainer bracket located under
one of the screws securing the right spindle
cover to the mower deck (Fig. 745).
Fig 743 PICT-7946
Fig 745 PICT-7947
5. Remove the right hand spindle cover (Fig. 746).
3. Remove the left hand spindle cover (Fig. 744).
Fig 746 PICT-7950a
Fig 744 PICT-7949
