ENGINE
4-6 GT Series Tractors Service Manual
4
3. Plug the wire harness into the engine harness (Fig.
406).
Fig 406 PICT-7605
 6OLGHWKHIXHOOLQHRQWRWKHIXHO¿OWHUDQGSRVLWLRQWKH
clamp to secure (Fig. 407).
Fig 407 PICT-7603
Engine Installation
1. Attach chains/straps and a hoist to the lift points on
the engine. Lower the engine into place on the frame
(Fig. 404).
Note: Take care to ensure the throttle and choke
cables are not caught between the engine and
the frame.
Fig 404 PICT-7613
2. Slide the positive wire onto the starter post. Install a
nut securing the positive wire to the starter assembly
(Fig. 405).
Fig 405 PICT-7610
