MOWER DECK
7-10 GT Series Tractors Service Manual
7
50” Mower Deck Spindle
Replacement
50” Mower Deck Spindle Removal
9. Raise the deck by moving the deck lift lever into the
top notch on the right fender (Fig. 774).
The following procedure was performed on the center
spindle assembly. The process is the same for all three
VSLQGOHDVVHPEOLHVH[FHSWZKHUHQRWHG
Fig 774 PICT-7837
1. Remove the mower deck from the tractor. Refer to
“50” Mower Deck Removal” on page 7-6.
2. If servicing a left or right spindle, remove the deck
belt from the mower deck. Refer to “50” Mower Deck
Belt Removal” on page 7-1.
3. Turn the mower deck over to access the underside
of the mower deck.
4. Block the mower deck blade and remove the nut
securing the mower deck blade to the spindle shaft
(Fig. 775).
Fig 775 PICT-7976
