Toro Multi Pro 5800-G - Removing the Shipping Bumper

g035648
Figure5
1.Section-hingespring3.Compressedspring
dimension—4cm(1-1/2
inches)
2.Jamnut
4.Repeattheprocedureforeachspringonboth
sectionhinges.
5.Movethesectionsintothetransport‘X’position.
SeeChangingtheSpraySectionPosition(page
39)formoreinformation.
3
RemovingtheShipping
Bumper
NoPartsRequired
Procedure
1.Removethebolts,washers,andnutsthat
securetheshippingbumpertothefrontchassis
plate(Figure6).
g028179
Figure6
1.Nut3.Washer
2.Shippingbumper
4.Bolt
2.Removetheshippingbumperfromthemachine
(Figure6).
Note:Discardthebolts,washers,nuts,and
shippingbumper.
