7.Swingthefueltankintothechassisandsecure
thefueltank;refertoAccessingtheEnginefrom
theLeftSide(page49).
ControlsSystem
Maintenance
AdjustingthePTOClutch
Gap
ServiceInterval:Every200hours
1.Parkthemachineonalevelsurface.
2.DisengagethePTO,lowerthemowerdeck,and
engagetheparkingbrake.
3.Raiseandsecurethehopper;refertoRaising
theHopper(page30)andSecuringtheHopper
intheRaisedPosition(page42).
4.Shutofftheengineandremovethekey.
5.Opentheengine-accesscover;referto
AccessingtheEnginefromtheEngine-Access
Cover(page49).
6.Adjusttheairgapsothata0.4mm(0.015inch)
feelergaugeslidesinbetweentheclutchlining
andfrictionplatewithlightpressure(Figure95).
Note:Youcandecreasethegapbyturning
theadjustingnutclockwise(Figure95).The
maximumservicegapis0.7mm(0.030inch).
Adjustall3airgaps.
g001252
Figure95
1.Clutch
4.Electricalconnector
2.0.4mm(0.015inch)air
gap(3)
5.PTObelt
3.Adjustingnut(3)
7.Afteryouhavesetall3gaps,checkthe3gaps
again.
Note:Adjusting1gapcanaltertheothergaps.
