Toro ProPass 200 Operator's Manual

g013207
Figure6
1.Packingstudsandfoam
6.Installthehopperguardusingthesupplied
button-headbolts(1/4x5/8inch)andnylon
locknuts(Figure7).
g030044
Figure7
1.Hopperfrontguard
2.Bolts
2
InstallingthePower
Harness
Partsneededforthisprocedure:
1Powerharness
1
Socketbracket
1
Socketbracket,heavy
2
Carriagescrew
2Flangenut
2
Screw
2Flangenut
Procedure
Thetowvehiclepowerharnessprovidestheelectrical
powerrequiredbythecontrolsystemsofthemachine.
Installthisharnessonthevehicleyouplantouse
tooperatethemachine.Ifyouwillusemorethan1
vehiclewiththemachine,purchaseadditionalpower
harnessesfromyourTorodistributor.
1.Mountthesocketbrackettoaxedpointatthe
rearofthetowvehicleusing1ofthemounting
bracketsprovided(Figure8).
Note:Ensurethatthebracketwillnotcome
incontactwithanythingifthetowvehicleis
equippedwithadumpbox.
Important:Ensurethatnoneofthewiring
islooseorinthewayofanymechanical
components.
