Figure48
1.JackstandsonTrucksterDirectConnect
UsingtheStorageStand
1.Parktheworkvehicleinthestoragespotforthe
machine.
Note:Thestoragespotmustbeahardand
levelsurface.
2.Disconnecttheelectricalconnectionfromthe
workvehicle.
3.Disconnectthemachinehydrauliclinesfromthe
workvehicle.
4.Withtheworkvehicleinneutralgear,engage
theparkingbrakeandstarttheengine.
5.Usingthevehicleliftcylinder,raisethefrontof
themachinehighenoughtoinstallthefront
storagestandlegs.
6.Shutofftheengine.
WARNING
Workingonthemachinewhileitison
thestoragestandcouldresultinserious
injuryordeath.
Donotclimbunderorperformworkon
themachinewhileitisonthestorage
stand.
7.Insertthefrontstoragelegsandtherearjack
standsintothemachinetubesandsecurethem
withthelockingpins(Figure49).
g013777
Figure49
1.Rearjackstands3.Lockingpin
2.Frontstoragelegs
8.Usingthevehicleliftcylinder,lowerthefrontof
themachineuntilthefrontstoragestandlegs
begintotouchtheground.
9.Raisethe2rearstoragejackstandsuntilthe
pressureisoffthemountingpinsthatsecurethe
machinecrosstubetotheWorkmanframe.
10.Removetherearlynchpins,hitchpins,and
washers(Figure50).
g013228
Figure50
1.Hitchpin,washers,andlynchpin
11.With1hand,holdtheliftcylinder.Withthe
otherhand,removetheliftcylinder’slockingpin
(Figure51).
36
