Toro ProPass 200 Operator's Manual

7
AssemblingtheHandheld
Remote
Model44751Only
Partsneededforthisprocedure:
1Handheldremote
4AAbatteries
1Magneticbracket
6
Screws,small
Procedure
1.Removetherubberbandssecuringtheremote
halvestogether,andremovethebackcover.
2.Installthebatteriesintotheterminalcradle
observingproperpolarity.(Ifthebatteries
areimproperlyinstalled,theunitwillnotbe
damaged,butitwillfailtooperate.)Thecradle
isembossedwithpolaritymarkingsforeach
terminal(Figure18).
g028875
Figure18
1.Rubberseal3.Handheldremote
2.Steelgasket
4.4AAbatteries
3.Ensurethatthesteelgasketandrubbersealare
seatedinthechannelintheremoteandsetthe
backcoverinplace(Figure18).
4.Securethecoverwith6screws(Figure18)and
torquethemto1.5to1.7N∙m(13to15in-lb).
5.Installthehandheldremoteintothemagnetic
remotebracket,slidethehalvestogetherto
securetheremote,andtightentheboltinthe
magnet(Figure19).
g028874
Figure19
1.Handheldremote3.Boltinthemagnet
2.Magneticremotebracket
8
MountingtheWireless
Remote
Model44751Only
Partsneededforthisprocedure:
1
Controllermountassembly
1Wirelessremoteassembly
Procedure
Insertthecontrollermountassemblyintoacupholder
orsimilaropeningonthetowvehicleandusetostore
wirelessremote.Also,thewirelessremotemagnet
willsticktoanymetalcomponent.
