Toro ProPass 200 - 5 Connecting the Intermediate Wire; 6 Connecting the On;Off Pendant; Harness

5
Connectingthe
IntermediateWireHarness
Partsneededforthisprocedure:
1Intermediatewireharness
Procedure
Plugtheintermediatewireharnessintothepower
harnessconnectoronthemachine(Figure15or
Figure16).
g237534
Figure15
Model44751
1.Powerharness2.Intermediatewireharness
g013948
Figure16
Model44701
1.Powerharness2.Intermediatewireharness
6
ConnectingtheOn/Off
Pendant
Model44701Only
Partsneededforthisprocedure:
1
On/offpendant
Procedure
Plugtheon/offpendantconnectorintotheconnector
onthemachine(Figure17).
g013947
Figure17
1.On/offpendant
