SettingUptheMachine
BaseModel
Partsneededforthisprocedure:
1Hopperguard
3
Buttonheadbolt(1/4x5/8inch)
3Locknut
Procedure
1.Removethebasemodelmachinefromthe
shippingcrate.
2.Attherearofthetwinspinner,removethebolt
andnutattachingthemachineliftingdevice
shippingbrackettothetwinspinner(Figure3).
g013203
Figure3
1.Shippingbracket
3.Atthefrontofthetwinspinner,removethe2
boltsandnutsattachingthemachinelifting
deviceshippingbrackettotheTwinSpinner
(Figure4).
g013204
Figure4
1.Shippingbracket
4.Liftthetwinspinneroutofthehopperusingthe
twinspinneroutergrabhandlesandplacethe
twinspinnerunitontheground(Figure5).
Note:Thissteprequires2people.
g013205
Figure5
1.Twinspinner
5.Removethe4screwsfromthelegsofthetwin
spinner.Withthehelpofapartner,liftthetwin
spinnerandremovethepackingstudsand
packingfoam(Figure6).
