Toro ProPass 200 Operator's Manual

PreparingtheMachinefor
Operation
Themachinefeaturesauniquecolor-codedoperationsystemthattakestheguess-workoutofsettingupyour
machine.Simplychoosethespread,identifythecolor,andthenadjusteachsettingtomatchthatcolorto
getaperfectspreadeverytime.
ChoosingtheSpread
Choosethespreadbyreadingthemainoperationdecalfoundonthetailgateofthemachine(Figure28).
decal119-6814
Figure28
1.Lightspreadspinneradjustmentsettings3.Warning—slideadjustmentandtailgateadjustment
2.Heavyspreadspinneradjustmentsettings
g013715
Figure29
Thisdecalshowstherangeofspreadsavailableandclassiesthembycolor(Figure29).Eachcolorrepresents
adifferentrateofapplicationfromUltra-LightthroughUltra-Heavy.Thespreaddensityisindicatedbythe
shadedovals(lightthroughheavy).Theapproximatewidthisalsoindicated
CheckingtheBlades
Note:Themachineisshippedwiththespinner
bladesinPOSITIONB.
Thelighterspreads(bluepanel)remindyoutoensure
thatthespinnerbladesareinPOSITIONA(Figure30).
g013716
Figure30
WhenthebladesareinPOSITIONA,theinsidebolts
(closesttothecenterofthedisc)aretighttothe
bladewallandtheoutsidebolts(closesttothe
edgeofthedisc)areawayfromthebladewall.
Thisiscriticalasthispositionisengineeredtogive
theoptimumspreadanddistributionathighspeeds
andlowsandvolume.
Forheaviersettings(goldpanel)thebladesshouldbe
inPOSITIONBtoprovidethebestdistributionathigher
volumesandslowerdiscspeeds(Figure31).
g013717
Figure31
WhenthebladesareinPOSITIONB,theinsidebolts
(closesttothecenterofthedisc)areawayfrom
thebladewallandtheoutsidebolts(closesttothe
edgeofthedisc)aretighttothebladewall.
Important:Incorrectbladepositionisacommon
reasonthatspreadpatternsfail.
