Toro ProPass 200 - 3 Installing the Hopper Extension Kit

g013261
Figure8
1.Socketbracket
2.Routeandsecuretheelectricalwiringfromthe
batterytotheelectricalplugbracket(Figure9).
g013262
Figure9
1.Whitewire(brass)3.Nowire(brass)
2.Nowiresilver(silver)4.Blackwire(brass)
3.Feedthewiringthroughthesocketbracketand
installtheblackrubbergrommetoverthewiring
(Figure9).
4.Boltthesockettothesocketbracketusingthe
bolts(1/4inch).
5.Connecttheredwire(power)tothepositive
postonthebattery,thenconnecttheblackwire
(ground)tothenegativepostonthebattery.
3
InstallingtheHopper
ExtensionKit
Partsneededforthisprocedure:
1
Hopperextension(front)
1
Hopperextension(rear)
9Bolt
9Flangenut
Procedure
1.Removethehopperextensionsfromthebox
andidentifythefrontandtherear(Figure10
andFigure11).
g013263
Figure10
1.Fronthopperextension(showingholeorientation)
g013264
Figure11
1.Rearhopperextension(showingholeorientation)
2.Usingthehardwareprovided,attachthehopper
extensionstothehopper.Placethenutsonthe
outsideofthehopper.
