g267326
Figure32
1.Bypassvalve
6.Towthemachineasrequiredusingthetie-down
locations(seeFigure35).
Important:Donotpushortowthemachine
fasterthan3to4.8km/h(2to3mph)for
longerthan3minutes,becauseyoumay
damagethetransmission.Thebypassvalves
mustbeopenwheneveryoupushortowthe
machine.
7.Closethebypassvalvesandtorquethemto70
N∙m(52ft-lb).
8.Removethescrewandinstalltheplugintoeach
trackdrivemotorandtorqueto8to12N∙m(71
to103in-lb)beforeoperatingthemachine.
9.Replaceanyuidlostduringthisprocedure;
refertoReplacingtheDrive-MotorPlanetary
GearOil(page42).
HaulingtheMachine
Useaheavy-dutytrailerortrucktohaulthemachine.
Useafull-widthramp.Ensurethatthetrailerortruck
hasallthenecessarybrakes,lighting,andmarkingas
requiredbylaw.Pleasecarefullyreadallthesafety
instructions.Knowingthisinformationcouldhelp
youorbystandersavoidinjury.Refertoyourlocal
ordinancesfortrailerandtie-downrequirements.
WARNING
Drivingonthestreetorroadwaywithout
turnsignals,lights,reectivemarkings,ora
slow-moving-vehicleemblemisdangerous
andcanleadtoaccidentscausingpersonal
injury.
Donotdrivethemachineonapublicstreet
orroadway.
SelectingaTrailer
WARNING
Loadingamachineontoatrailerortruck
increasesthepossibilityoftip-overandcould
causeseriousinjuryordeath(Figure33).
•Useonlyfull-widthramps.
•Ensurethatthelengthoframpisatleast4
timesaslongastheheightofthetraileror
truckbedtotheground.Thisensuresthat
rampangledoesnotexceed15degreeson
atground.
g229507
Figure33
1.Full-widthramp(s)in
stowedposition
3.H=heightofthetraileror
truckbedtotheground
2.Rampisatleast4times
aslongastheheightof
thetrailerortruckbedto
theground
4.Trailer
