Important:Donotsubstituteanautomotiveoil
lter;otherwise,severehydraulicsystemdamage
mayoccur.
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowertheloaderarms.
2.Shutofftheengineandremovethekey.
3.Raisetheloaderarmsandinstallthecylinder
locks.
4.Removethefrontcover;refertoRemovingthe
FrontCover(page32).
5.Placeadrainpanunderthefrontlterand
replacethelter(Figure80).
g263539
Figure80
6.Cleanupanyspilleduid.
7.Opentherearaccesscover;refertoOpening
theRear-AccessCover(page31)
8.Removetherearscreen;refertoRemovingthe
RearScreen(page31).
9.Placeadrainpanundertherearlterand
replacethelter(Figure81).
g263575
Figure81
10.Cleanupanyspilleduid.
11.Starttheengineandletitrunforabout2minutes
topurgeairfromthesystem.
12.Shutofftheengineandcheckforleaks.
13.Checktheuidlevelinthehydraulictank;refer
toCheckingtheHydraulic-FluidLevel(page
50)andadduidtoraisetheleveltomarkon
dipstick.
Important:Donotoverllthetank.
14.Installthefrontcover.
15.Installtherearscreenandtightentheknobsand
boltstosecureit.
16.Closetherear-accesscoverandinstallthe
fastenertosecureit.
17.Removeandstorethecylinderlocksandlower
theloaderarms.
