Toro TXL 2000 - Replacing the Fuel Filter Canister; Checking the Fuel Lines and Connections; Bleeding the Fuel System; Draining the Fuel Tank(S)

ReplacingtheFuelFilter
Canister
ServiceInterval:Every400hours
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowertheloaderarms.
2.Shutofftheengineandremovethekey.
3.Opentherearaccesscover;refertoOpening
theRear-AccessCover(page31)
4.Removetherearscreen;refertoRemovingthe
RearScreen(page31)
5.Placeacleancontainerunderthefuellter
canister(Figure58).
g261736
Figure58
1.Fuelltercanister
6.Removetheltercanisterandcleanthe
mountingsurface.
7.Lubricatethegasketonthenewltercanister
withcleanoil.
8.Fillthecanisterwithfuel.
9.Installtheltercanisterbyhanduntilthegasket
contactsthemountingsurface,thenrotateitan
additional1/2turn.
10.Installtherearscreenandtightentheknobsand
boltstosecureit.
11.Closetherear-accesscoverandinstallthe
fastenertosecureit.
CheckingtheFuelLines
andConnections
ServiceInterval:Every400hours/Yearly(whichever
comesrst)
Inspectthefuellinesandconnectionsfordeterioration,
damage,orlooseconnections.Tightenanyloose
connectionsandcontactyourAuthorizedService
Dealerforassistanceinxingdamagedfuellines.
BleedingtheFuelSystem
Youmustbleedthefuelsystembeforestartingthe
engineifanyofthefollowingsituationshaveoccurred:
•Initialstartupofanewmachine
•Theenginehasceasedrunningduetoalackof
fuel.
•Maintenancehasbeenperformedupon
fuel-systemcomponents(e.g.,lterreplaced).
Usethemanualpumponthewaterseparatortobleed
airoutofthefuelsystem.
g263481
Figure59
1.Manualpump
DrainingtheFuelTank(s)
ServiceInterval:Every500hours
HaveanAuthorizedServiceDealerdrainandclean
thefueltank(s).
38
