1. OUTLINE EO18-33025
1.1 Feature of the B-EV4D/EV4T
1-1
1. OUTLINE
1.1 Feature of the B-EV4D/EV4T
1.1.1 Front View
(1) B-EV4D
(2) B-EV4T
FEED Button
Media Outle
t
STATUS Lamp
Media View Window
Top Cover Release Button
SD Card Slot
FEED Button
Media Outle
t
STATUS Lamp
Media View Window
Top Cover Release Button
SD Card
Slot Cover
SD Card Slot
SD Card
Slot Cover

Toshiba B-EV4 Series Specifications

General

Print Method	Direct Thermal / Thermal Transfer
Power Supply	AC 100-240V, 50/60 Hz
Operating Temperature	5°C to 40°C
Print Resolution	203 dpi, 300 dpi
Max Print Speed	Up to 127 mm/sec (5 ips) (203 dpi) / Up to 101.6 mm/sec (4 ips) (300 dpi)
Interface	USB, Serial
Optional Interfaces	Wireless LAN
Weight	2.4 kg
Barcodes	Code 39, Code 128
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code
Media Width	25.4 mm to 112 mm
Media Thickness	0.06 mm to 0.19 mm
Media Roll Diameter	Max. 127 mm
Ribbon Width	40 mm to 110 mm
Ribbon Length	300 m
Operating Humidity	25% to 85% non-condensing
