Toshiba B-EV4 Series - Rear View

1. OUTLINE EO18-33025
1.1 Feature of the B-EV4D/EV4T
1-2
1.1.2 Rear View
1.1.3 Interior
(1) B-EV4D
Power Jack
Power Switch
Fanfold paper slo
t
Parallel Interface
Connector (Centronics)
USB Interface
Connecto
r
Serial Interface Connector (RS-232C)
Ethernet interface
Top Cover
Media Guide
Media Holder Lock Switch
Black Mark Sensor
Cover Open Senso
r
Feed Gap Sensor
(Receiver)
Media Guide
A
d
j
ustment Dial
Print Head
Media Holde
r
Platen
Feed Gap Sensor
(Transmitter)
