1. OUTLINE EO18-33025
1.1 Feature of the B-EV4D/EV4T
1-3
(2) B-EV4T
Ribbon Rewind Gea
r
Media Guide
Media Holde
r
Lock Switch
Black Mark Sensor
Cover Open
Senso
r
Feed Gap Senso
r
(Receiver)
Media Guide
Adjustment Dial
Print Head
Media Holde
r
Top Cover
Platen
Spring Guide Wheel (Take-up side)
Feed Gap Sensor (Transmitter)
Ribbon Access Cover
Spring Guide Wheel (Supply side)
