2. MAJOR UNIT REPLACEMENT
EO18-33032
2.8 Replacing the Peel-Off Unit
2-24
4) Pull the metal shaft in the direction of the arrow.
5) Remove the Print Head. (Refer to Section 2.5 Replacing the Print Head.)
Metal
shaft
Metal
shaft
