Toshiba HDR5010KB User Manual

Main Menu Options
Edit Channel List Menu
•
Hide Channels
Allows you to hide unwanted channels. Press the [OK] button to select a channel to hide.
•
Sort Channels
Allows you to rearrange the channel order. Press the [OK] button to select the channel
you wish to move. Press [ ] or [ ] to select the new position, then press the [OK] button.
Settings Menu
•
General Settings
Audio
Allows you to set your preferred audio setting (if available).
HDMI Output
Allows you to change the HDMI output resolution. Default setting is Auto. This selects
the best possible resolution supported by your TV. If preferred the resolution can be
changed. Refer to page 45 for more information.
TV Out
Allows you to switch the SCART output between RGB and CVBS. The default setting is
RGB which gives you the best picture quality. If your TV is not compatible with RGB or
you are having problems with the picture, switch to CVBS.
Picture Mode
Allows you to switch between widescreen, 4:3 normal and 4:3 letterbox picture.
Widescreen
This is the default setting and is best if you have a widescreen
TV.
4:3 normal
Choose this option if you do not want to have a black bar at
the top and bottom of the screen. Programmes broadcast in
widescreen will fill the whole screen but you will lose the left and
right edges of the picture.
4:3 letterbox
We recommend you choose this option if you have an older
4:3-format TV. Any programmes broadcast in widescreen will fit
onto the screen, but will have a black bar at the top and bottom.
Using your Digital TV recorder
34
HDR5010 User Guide.indb 34 8/6/10 09:08:29

Toshiba HDR5010KB Specifications

General

USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
HDD capacity	500 GB
Product color	Black
Power consumption (typical)	30 W

Weight and Dimensions

Weight	2860 g
Dimensions (WxDxH)	360 x 270 x 60 mm
