Toshiba HDR5010KB User Manual

Specifications
Physical Specification
Size (W) 360mm x (H) 60mm x (D) 270mm
Weight 1.9 kg
Power Requirements
Input voltage 12V DC 2.5A (with supplied AC mains adaptor)
DC jack connector 6mm (2.1mm Pin) DC Jack
Power consumption (On) < 30W Max
Power consumption (STBY) < 1W
Operating temperature +5˚C to +40˚C
Storage temperature -20˚C to +60˚C
Twin Tuners
RF input / output connectors 1x IEC 75R (female) / 1x IEC 75R (male)
Channel coverage UHF 474~850MHz (B21~B68)
Demodulator
Modulation Standard Definition
OFDM/QPSK, 16QAM, 64QAM
FFT: 2k, 8K
Code Rate: 1/2, 2/3, 3/4, 5/6, 7/8
Guard Interval: 1/32, 1/16, 1/8, 1/4
High Definition
OFDM/QPSK, 16QAM,64QAM, 256QAM
FFT: 1K, 2K, 4K, 8K, 8Kext, 16K, 16Kext,32K, 32Kext
Code Rate: 1/2, 3/5, 2/3, 3/4, 4/5, 5/8
Guard Interval: 1/4, 1/8, 1/16, 1/32, 1/128, 19/128, 19/256
Video Decoder
Video decoding Standard Definition – MPEG2 Main level / Main profile
High Definition – MPEG-4 AVC
Video formats 16:9 / 4:3 Letterbox / 4:3
Audio Decoder
Audio decoding Standard Definition – MPEG-2 layer 1 and 2
High Definition – Dolby E-AC3 / MPEG-4 HE-AAC
Audio mode Mono / Stereo / Dual
AV Connectors
HDMI input ports 2 x HDMI type A (19-pin) - selectable
HDMI output port 1 x HDMI type A (19-pin)
Additional Information
44
HDR5010 User Guide.indb 44 8/6/10 09:08:30

Toshiba HDR5010KB Specifications

General

USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
HDD capacity	500 GB
Product color	Black
Power consumption (typical)	30 W

Weight and Dimensions

Weight	2860 g
Dimensions (WxDxH)	360 x 270 x 60 mm
