Toshiba HDR5010KB User Manual

Video output 21-pin SCART connector - Composite video
(1.0 V pk to pk 75 ohm)
RGB (0.7V pk to pk 75 ohm)
Audio output 21-pin SCART connector - Left & Right audio
(2V rms 10K ohm)
Audio line out Digital optical (SPDIF) – TOS link connector
Data Connectors
Front of unit
USB port USB-A female connector / 500mA
Rear of unit
USB port USB-A female connector / 500mA
Ethernet port RJ45 connector Ethernet (10 Base-T / 100 Base-Tx) / HP
Auto MDI/MDI-X
Media Storage Device
SATA HDD (Hard Disk Drive) 500GB, 3.5” platter
Photo Viewer
Supported formats JPG, .BMP, .PNG
Supplied Accessories
Remote control
Batteries (2x AAA/R03)
Owner’s manual
Quick start guide
Help leaflet
AC mains adaptor
Design and specifications are subject to change without notice. All information correct at time of going to press.
HDMI v1.3a Inputs – Supported
Resolutions (pass-through)
HDMI Output
(not from HDMI pass-through)
No. Signal name No. Signal name
1 480i/480p 1 1080p
2 576i/576p 2 1080i
3 720p 3 720p
4 1080i 4 576p
5 1080p 5 576i
8 HDCP (pass-through)
9 CEC (pass-through)
Specifications
Additional Information
45
HDR5010 User Guide.indb 45 8/6/10 09:08:31

Toshiba HDR5010KB Specifications

General

USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
HDD capacity	500 GB
Product color	Black
Power consumption (typical)	30 W

Weight and Dimensions

Weight	2860 g
Dimensions (WxDxH)	360 x 270 x 60 mm
