4.4 ExpressCard 4 Replacement Procedures
PORTÉGÉ R830/Satellite R830 Maintenance Manual (960-880) [CONFIDENTIAL] 4-13
4.4 ExpressCard
Removing the ExpressCard
To remove the ExpressCard, follow the steps below and refer to Figure 4-3.
CAUTION: Before you remove the ExpressCard, refer to the card’s documentation and
to your operating system documentation for proper procedures and
precautions.
1. Push the ExpressCard. It will pop out partly, so pull out the card.
Figure 4-3 Removing the ExpressCard
Installing the ExpressCard
To install the ExpressCard, follow the steps below and refer to Figure 4-3.
1. Insert the ExpressCard and press it until it is securely connected.
ExpressCard
