Appendices Appendix C Pin Assignments
C-24 [CONFIDENTIAL] PORTEGE R830 Satellite R830 Series Maintenance Manual (960-880)
C.23 CN9560 Smart Card interface connector (10-pin)
Table C- 23 Smart Card interface connector (10-pin)
Pin No. Signal Name Pin No. Signal Name
1 GND 2 GND
3 GND 4 GND
5 GND 6 SCRMDL-P3N
7 GND 8 ZUSBSC-E3P
9 ZUSBSC-E3N 10 GND
11 PLTRS3-E3N 12 P3V
13 NC 14 P5V
1T GND 2T GND
C.24 CN9571 FAL3U3* board interface connector (25-pin)
Table C- 24 FAL3U2* board interface connector (25-pin)
Pin No. Signal Name Pin No. Signal Name
1
E3V 2
US3XRQ-E3N
3 1R05-E1V 4 1R05-E1V
5
PEWAKE-E3N
6
PLTRST-N
7
US3SMI-E3N
8
GND
9
XPEUS3-P0P
10
XPEUS3-P0N
11
GND
12
ZERUS3-P1P
13
ZERUS3-P1N
14
GND
15
ZETUS3-P1P
16
ZETUS3-P1N
17
GND
18
US3MDL-P3N
19
RSMRST-N
20
GND
21
GND
22
GND
23
GND
24
GND
25
GND
1T
GND
2T
GND

Toshiba Portege R830 Specifications

General

Resolution	1366 x 768
Graphics	Intel HD Graphics 3000
Optical Drive	DVD SuperMulti Drive
Bluetooth	Bluetooth 3.0
Display	13.3 inches
Operating System	Windows 7 (various editions)
Weight	3.1 lbs
Battery Life	Up to 9 hours
Wireless	802.11 g/n
Ports	USB 3.0, VGA, HDMI, Ethernet
