STE 80897
– 1–3 –
TRANSPORTATION & INSTALLATION MANUAL
4) Lift up the robot carefully, using the crane.
Next, disconnect the robot body from the transport fixtures to carry the robot.
5) Remove the hexagon socket head cap screws and washers, then mount the
M10 eyebolts in the screw holes instead.
6) Remove the arm clamps and move so that the arms can overlap each other.
7) Pass wire ropes through the eyebolts. To assure safety, be sure to use the
four (4) wire ropes. If there is a fear that the wire rope will contact the robot
body due to the length of the wire rope, use a cushion.
8) After the installation, remove the eyebolts and mount the attached hexagon
socket head cap screws and washers in the screw holes.
Fig. 1.2 Lifting posture of the robot (double-hand specifications)
Eyebolt 10
4 places
Arm clamp
Transport fixture
Hexagon socket
head cap screw
and washer
Position the
cushions
Wire rope
To Next Page
