TRANSPORTATION & INSTALLATION MANUAL
3.3.5 Dimensions when Separating Control Panel
Fig. 3.7 shows the connections of the control panel and dummy panel. Provide a
clearance of about 50.6 mm on the rear side of the separated control panel.
When the cable is connected to the dummy panel of the controller, provide a clearance
of 80 mm or so in front of the controller as the cable connector sticks out of the panel
surface.
Fig. 3.7 Cable connections of dummy panel and control panel
80mm
50.6mm
