STE 80897
– 3–8 –
TRANSPORTATION & INSTALLATION MANUAL
!
CAUTION
1. If the signals of SVOFF and emergency stop contacts 1, 2 are jumpered,
the controller servo power cannot be turned on.
2. Unless the CYCLE signal is jumpered, the controller enters the cycle
operation mode.
3. Unless the LOW_SPD signal is jumpered, the robot is operated at low
speed during automatic operation.
4. Unless the STOP signal is jumpered, automatic operation of the robot is not
possible.
To Next Page
