E6581581
- 18 -
3.2.4.11. FD03 (Output current (real time))
The output current is read into 0.01% of units and by the hexadecimal number.
For example, when the output current of the rated current 4.8A inverter is 50% (2.4A), 0x1388
(hexadecimal number) is read.
Since the minimum unit is 0.01%,
0x1388 (Hex.) = 5000 (Dec.) * 0.01 = 50 (%)
Also about the following parameters, these are the same as this.
- FD05 (Output voltage(real time) ................................................... Unit: 0.01% (V)
- FD04 (Voltage at DC bus (real time) ............................................ Unit: 0.01%(V)
- FD18 (Torque) .............................................................................. Unit: 0.01% (Nm)*
* When the motor information connected to the inverter set to the parameter (f405 - f415), torque
monitor value "100%" is same as the rated torque of a motor in general.
3.2.4.12. FE36 (Analog input value VI/II)
The value inputted into the VI/II terminal is read.
The value range is 0x0 to 0x2710 (0 to 100.00 %).
- Also about FE35 (RR Input), it is the same as this parameter.
3.2.4.13. FE37 (RX Input)
The value inputted into the RX terminal is read.
The value range is 0xD8F0 to 0x2710(-100.00 to +100.00 %).
3.2.4.14. FE60 - FE63 (My Monitor)
Refer to the function Manual (E6581335).
3.2.4.15. FE14 (Cumulative run time)
The operated cumulative time is read by the hexadecimal number.
For example, when cumulative operation time is 18 hours, 0x12 (Hex) is read.
0x12 (Hex.) = 18 (Dec., hour)
3.2.4.16. FE40 (Analog output (FM))
The output value of FM terminal is read.
The value range is set to 0 to 10000 (0x2710).
- Also about FE41 (AM terminal output monitor), it is the same as this parameter.
