5.1.16. Instance 104: Allen Bradley Drive Profile Input
Instance 104 mapping
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0
1=Fault
1=Alarm
- -
0 = Forward
1 = Reverse
- 1=Running 1=Ready
1
Setpoint source:
0000 = not used
0001 = Terminal VI/II(AI2)
0010 = Terminal RR(AI3)
0011 = Terminal RX(AI1)
0100 = Keypad
0101 = Serial link (2 wire)
0110 = Serial link (4 wire)
0111 = EtherNet/IP™ card
1000 = Analog1 (option RX2)
1001 = Analog 2 (option VI2)
1010 = TB Up/Down frequency
1011 = Pulse input (option)
1100 = Pulse input (motor CPU)
1101 = not used
1110 = not used
1111 = preset speed (CMOD high priority)
Control source:
000 = Terminals
001 = Key pad
010 = Serial link (2 wire)
011 = Serial link (4 wire)
100 = EtherNet/IP™ card
101 = not used
110 = not used
111 = not used
1=At reference
speed
2
Drive Actual Speed Hz (Low byte)
3
Drive Actual Speed Hz (High byte)
4 f841 Monitor data (Low byte)
5 f841 Monitor data (High byte)
6 f842 Monitor data (Low byte)
7 f842 Monitor data (High byte)
8 f843 Monitor data (Low byte)
9 f843 Monitor data (High byte)
10 f844 Monitor data (Low byte)
11 f844 Monitor data (High byte)
12 f845 Monitor data (Low byte)
13 f845 Monitor data (High byte)
14 f846 Monitor data (Low byte)
15 f846 Monitor data (High byte)
16 f847 Monitor data (Low byte)
17 f847 Monitor data (High byte)
18 f848 Monitor data (Low byte)
19 f848 Monitor data (High byte)
Please refer to "3.2.4 Command data (f831-f838), Monitor data (f841-f848)" for the details of parameter
f841 -
f848.
