Toshiba TOSVERT VF-AS1 Series User Manual

E6581581
- 19 -
3.2.4.17. FC91 (Alarm code)
bit Function 0 1 Note
0 Over current alarm Normal Alarming “c” blinking
1 Inverter over load alarm Normal Alarming “l” blinking
2 Motor over load alarm Normal Alarming “l” blinking
3 Over heat alarm Normal Alarming “h” blinking
4 Over voltage alarm Normal Alarming “p” blinking
5 Under voltage of main power Normal Alarming -
6 (Undefined) - - -
7 Under current alarm Normal Alarming -
8 Over torque alarm Normal Alarming -
9 OLr alarm Normal Alarming -
10 Cumulative run-time alarm Normal Alarming -
11 (Undefined) - - -
12 (Undefined) - - -
13 (Undefined) - - -
14
At the time of the instant blackout, Forced
deceleration/ stop
-
Decelerating,
stopping
Related: uvc setting
15
An automatic stop during the lower limit
frequency continuance
-
Decelerating,
stopping
Related: f256 setting
3.2.4.18. FD06 (Input terminal board status)
bit TB Name Function (Parameter) 0 1
0 F Input TB Function select 1 (f111)
1 R Input TB Function select 2 (f112)
2* ST Input TB Function select 3 (f113)
3 RES Input TB Function select 4 (f114)
4 S1 Input TB Function select 5 (f115)
5 S2 Input TB Function select 6 (f116)
6 S3 Input TB Function select 7 (f117)
7 S4 Input TB Function select 8 (f118)
8 L1 Input TB Function select 9 (f119)
9 L2 Input TB Function select 10 (f120)
10 L3 Input TB Function select 11 (f121)
11 L4 Input TB Function select 12 (f122)
12 L5 Input TB Function select 13 (f123)
13 L6 Input TB Function select 14 (f124)
14 L7 Input TB Function select 15 (f125)
15 L8 Input TB Function select 16 (f126)
OFF ON
* This function is reserved in VF-PS1.
3.2.4.19. FD07 (Output terminal board status)
bit TB Name Function (Parameter) 0 1
0 OUT1 Output TB Function select 1 (f130)
1 OUT2 Output TB Function select 2 (f131)
2 FL Output TB Function select 3 (f132)
3 OUT3 Output TB Function select 4 (f133)
4 OUT4 Output TB Function select 5 (f134)
5 R1 Output TB Function select 6 (f135)
6 OUT5 Output TB Function select 7 (f136)
7 OUT6 Output TB Function select 8 (f137)
8 R2 Output TB Function select 9 (f138)
9 R3 Output TB Function select 10 (f168)
10 R4 Output TB Function select 11 (f169)
OFF ON
11 - 15 (Undefined) - - -

Toshiba TOSVERT VF-AS1 Series Specifications

General

Category	Inverter
Input Frequency	50/60 Hz ±5%
Series	VF-AS1
Overload Capacity	150% for 60 seconds
Input Voltage	3-phase 200 to 240 VAC
Protection Degree	IP20
Ambient Temperature	-10 to +50 °C (14 to 122°F) (Open type)
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Ground Fault
Braking Unit	Built-in
Communication	RS485
Power Range	0.4 to 110 kW
Cooling Method	Forced Air Cooling
Operating Temperature	-10 to +50 °C (14 to 122°F) (Open type)
Altitude	Up to 1000 m
Output Voltage	3-phase, voltage corresponding to input voltage
