E6581581
- 22 -
*Note: STRINGI have the following format
Number of bytes Means Default for Assigned Name
1
Number of string
0x01
3 Language set ‘eng’ (0x65 0x6E 0x67)
1 EPATH 0xDA
2 Character Set 0x04 0x00
1 Length 16 (0x10)
Length Value ‘User Name String’
(0x55 0x73 0x65 0x72 0x20 0x4E 0x61 0x6D 0x20 0x53 0x74 0x72 0x69 0x6E
0x67)
Attribute 5
State Descriptions
Adapted from document [CIP] “
THE CIP NETWORKS LIBRARY”
Bit Called Definition
0 Owned
TRUE indicates the device (or an object within the device) has an owner.
Within the Master/Slave paradigm the setting of this bit means that the
Predefined Master/Slave Connection Set has been allocated to a master.
Outside the Master/Slave paradigm the meaning of this bit is TBD.
unused
1 Reserved, shall be 0 Reserved, shall be 0
2 Configured.
TRUE indicates the application of the device has been configured to do
something different than the “out–of–box” default. This shall not include
configuration of the communications.
3 Reserved, shall be 0 Reserved, shall be 0
0 Self-Testing or Unknown
1 Firmware Update in Progress
2 At least one faulted I/O connection
3 No I/O connections established
4 Non-Volatile Configuration bad
5 Major Fault – either bit 10 or bit 11 is true (1)
6 At least one I/O connection in run mode
7 At least one I/O connection established, all in idle mode
8 Reserved, shall be 0
4-7
Extended Device
Status
9-15
Vendor/Product specific unused
8
Minor Recoverable
Fault
TRUE indicates the device detected a problem with itself, which is thought to
be recoverable.
The problem does not cause the device to go into one of the faulted states.
9
Minor
Unrecoverable
Fault.
TRUE indicates the device detected a problem with itself, which is thought to
be unrecoverable. The problem does not cause the device to go into one of
the faulted states.
10
Major Recoverable
Fault.
TRUE indicates the device detected a problem with itself, which caused the
device to go into the “Major Recoverable Fault” state.
11
Major
Unrecoverable Fault
TRUE indicates the device detected a problem with itself, which caused the
device to go into the “Major Unrecoverable Fault” state.
12-15 Reserved, shall be 0 Reserved, shall be 0
