E6581697
G-10
7
(4) Holding the output of signals in ON status
, If the conditions for activating the functions assigned to output terminals RY-RC and OUT-NO agree with
and as a result the output of signals is put in ON status, the output of signals is held ON, even if the
conditions change. (Output terminal holding function)
, Assign input terminal function 80 to 83 to a logic input terminal available.
â– Input terminal function
Function No. Code Function Action
80 HDRY
Holding of RY-RC terminal
output
ON: Once turned on, RY-RC are held on.
OFF: The status of RY-RC changes in real
time according to conditions.
82 HDOUT
Holding of OUT-NO terminal
output
ON: Once turned on, OUT-NO are held on.
OFF: The status of OUT-NO changes in real
time according to conditions.
Each of the following numbers (81, 83) are reverse signals.
, Once output terminal RY-RC or OUT-NO is turned on when the contact input terminal to which one of the
above functions (function 80 to 83) is assigned is ON, output terminal RY-RC or OUT-NO is held ON.
To Next Page
