5. Functions
This option is a communication interface unit that allows the PLC program to operate, monitor
and set the parameter of the inverter as a remote station of CC-Link. It is able to communicate
with a maximum speed of 10Mbps not only transmitting bit data but also by word data.
Moreover, more data transmissions are possible by the use of CC-Link V2.0.
5.1. Initial setting
Set the following parameters of the inverter.
Title
Function Description
Factory
setting
CC-Link
setting
cmod
Command mode
selection
0: Terminal board
1: Panel keypad (including remote keypad)
2: RS485 communication
3: CANopen communication
4: Communcation option
1 4
fmod
Frequency setting
mode selection 1
0: Setting dial 1 (save even if power is off)
1: Terminal board VIA
2: Terminal board VIB
3: Setting dial 2 (press in center to save)
4: RS485 communication
5: UP/DOWN from external logic input
6: CANopen communication
7: Communication option
8: Terminal board VIC
9, 10: -
11: Pulse train input
12, 13: -
14:
sro
0 7
f856
Number of motor
pole for
communication
1: 2 poles
2: 4 poles
3: 6 poles
4: 8 poles
5: 10 poles
6: 12 poles
7: 14 poles
8: 16 poles
2 *
f899
Communication
function reset
0: -
1: Reset (after execution: 0)
0 -
*Set parameter according to number of motor pole used.
