1. Overview
The option allows the VF-S15 drive to be connected into a CC-Link network. CC-Link supports a
maximum of 42 nodes, allowing for the Master and this option is based on CC-Link V1.1 and V2.0.
The CCL-003Z is able to operate RUN/STOP, monitor the status of the drive, set the drive’s parameter
and etc. by the CC-Link master through installing the VF-S15. And it can use various applications.
2. Basic specifications
<Environmental specification>
Item Specification
Operating
environment
Indoors, an altitude of 3,000m or less, where the product will not be exposed
to direct sunlight, corrosive or explosive gasses, vapor, coarse particulates
including dust and where there is no grinding fluid or grinding oil nearby.
Ambient
temperature
0 to + 60 degreeC
Storage
temperature
-25 to +65 degreeC
Related
temperature
20 to 93% (no condensation and absence of vapor)
Vibration 5.9 m/s
2
(0.6G) or less (10 – 55Hz)
<CC-Link communication and option specification>
Item Specification
Number of units
corrected
42 units max. (1 station occupied by 1 unit). May be used with other
equipment.
Baud rate 156k, 625k, 2.5M, 5M, 10Mbps
Power supply Supplied from SBP009Z
Station type Remote device station
Number of stations
occupied
Ver.1: occupies one station, V2: occupies one station (selectable from among
double, quadruple and octuple)
Connect cable CC-Link dedicated cable,
CC-Link V1.10 compatible CC-Link dedicated cable
