5.3. CC-Link function setting
5.3.1. Station number setting
Use parameter c120 to set station number of the inverter.
Set this parameter within the range of 1 to 64.
Title
Function Description
c120
CC-Link station
number selection
1 to 64
*Use different station numbers for different devices. (If different devices have the same station
number, the communication cannot be performed properly.)
･ Set consecutive numbers for the station numbers. (Do not skip a number in sequence
like "station number 1 - station number 2 - station number 4".)
･The station number does not have to match with the physical connection sequence.
(There is no problem with having the physical connection sequence like "station
number 1 - station number 3 - station number 4 - station number 2".)
･ One inverter occupies one station. (One remote device station)
･ "L.ERR" LED flickers if the setting is changed. When power is switched on again,
reset by parameter (
f899 = 1) or the RES signal is turned on, the setting value is
reflected and the LED turns off.
5.3.2. Baud rate setting
Set the transmission speed. (Refer to the manual for the CC-Link master module for
details of transmission speed.)
Title
Function Description
c121
CC-Link baud rate selection
0: 156kbps
1: 625kbps
2: 2.5Mbps
3: 5Mbps
4: 10Mbps
･ "L.ERR" LED flickers if the setting is changed. When power is switched on again,
reset by parameter (
f899 = 1) or the RES signal is turned on, the setting value is
reflected and the LED turns off.
