Toshiba TOSVERT VF-S15 series Function Manual

E658130
- 5 -
2.1. CC-Link Version
2.1.1. CC-Link Ver. 1.10
The conventional CC-Link products, whose inter-station cable lengths have equally been
changed to 20cm (7.87 inch) or more to improve the inter-station cable length restriction,
are defined as CC-Link Ver. 1.10. In comparison the conventional products are defined
as CC-link Ver. 1.00.
Refer to the CC-link Master Module Manual for the maximum overall cable lengths and
inter-station cable lengths of CC-Link Ver. 1.00 and Ver. 1.10
CC-Link Ver. 1.10 compatibility conditions
1) All modules that comprise a CC-Link system should be compatible with CC-Link Ver.
1.10.
2) All data link cables should be CC-Link Ver. 1.10 compatible, CC-Link dedicated cables.
(CC-Link Ver.1.10 compatible cables have a logo or Ver. 1.10 indication.)
*In a system that uses the CC-Link Ver. 1.00 and Ver. 1.10 modules and cables together,
the maximum overall cable length and inter-station cable length are as specified for
CC-Link Ver. 1.00.
2.1.2. CC-Link Ver. 2
The CCL003Z is compatible with CC-Link Ver.2.
When using the CC-Link Ver.2 setting with the CCL003Z, the master station needs to be
compatible with the CC-Link Ver.2.
For CC-Link Ver.2, double, quadruple and octuple settings can be used to increase
remote register (RWw/r) point.

Toshiba TOSVERT VF-S15 series Specifications

General

Series	VF-S15
Category	Inverter
Control Method	V/f control, Sensorless vector control
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication Options	Modbus
Braking Unit	Built-in
Power Rating	0.4 kW to 15 kW
Input Voltage	Single-phase 200 to 240V, Three-phase 200 to 240V, 380 to 480V
Cooling Method	Fan cooling
