Toshiba TOSVERT VF-S15 series Function Manual

E658130
- 34 -
5.5.12. Description of input terminal information
Data composition of input terminal information (Code No. = 0FH).
Bit Terminal name Function (parameter name) 0 1
0 F Input terminal function selection
1A(f111) / 1B(f151) /
1C(f155)
1 R Input terminal function selection
2A(f112) / 2B(f152) /
2C(f156)
2 RES Input terminal function selection
3A(f113) / 3B(f153)
3 S1 Input terminal function selection
4A(f114) / 4B(f154)
4 S2 Input terminal function selection
5(f115)
5 S3 Input terminal function selection
6(f116)
6 VIB Input terminal function selection
7(f117)
7 VIA Input terminal function selection
8(f118)
OFF ON
8 to 15 － － － －
5.5.13. Description of output terminal information
Data composition of input terminal information (Code No. = 10H).
Bit Terminal name Function (parameter name) 0 1
0 RY-RC Output terminal function selection
1A(f130) / 1B(f137)
1 OUT Output terminal function selection
2A(f131) / 2B(f138)
2 FL Output terminal function selection
3(f132)
OFF ON
3 to 15 － － － －

Toshiba TOSVERT VF-S15 series Specifications

General

Series	VF-S15
Category	Inverter
Control Method	V/f control, Sensorless vector control
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication Options	Modbus
Braking Unit	Built-in
Power Rating	0.4 kW to 15 kW
Input Voltage	Single-phase 200 to 240V, Three-phase 200 to 240V, 380 to 480V
Cooling Method	Fan cooling
