Toshiba TOSVERT VF-S15 series Function Manual

E658130
- 33 -
5.5.11. Description of monitor code
Divide the monitor code (RWw n) into half and select the monitor value 1 (RWr n) from the
lower 8 bits and the monitor value 2 (RWr n) from the upper 8 bits.
For Example: When output voltage is selected for the monitor value 1 and output torque is
selected for the monitor value 2. -> The monitor code is 0703H.
Address Upper 8 bits Lower 8 bits
RWw n
Monitor value
2
Monitor value 1
RWw n+4 - Monitor value 3
RWw n+5 - Monitor value 4
RWw n+6 - Monitor value 5
RWw n+7 - Monitor value 6
Monitor code (When an invalid monitor code is set up, monitor value fixes to 0.)
Code Number
Second Monitor Description
(upper 8 bits)
First Monitor Description
(lower 8 bits)
Unit
00H
Output frequency
(Only the second monitor )
None monitor (Monitor value is 0) 0.01Hz
01H Output frequency Output frequency 0.01Hz
02H Output current Output current 0.01A
03H Output voltage Output voltage 0.1V
04H None monitor (Monitor value is 0) None monitor (Monitor value is 0)
－
05H Frequency command value Frequency command value 0.01Hz
06H Output speed Output speed 1min
-1
07H Output torque (With sign) Output torque (With sign) 0.1%
08H DC voltage DC voltage 0.1V
09H PBR load factor PBR load factor 0.1%
0AH Motor overload factor Motor overload factor 0.1%
0BH・0CH
None monitor (Monitor value is 0) None monitor (Monitor value is 0)
－
0DH Input power Input power 0.01kW
0EH Output power Output power 0.01kW
0FH Input terminal information Input terminal information
－
10H Output terminal information Output terminal information
－
11H Output current Output current 0.1%
12H Exciting current Exciting current 0.01A
13H None monitor (Monitor value is 0) None monitor (Monitor value is 0)
－
14H Cumulative operation time Cumulative operation time 1h
15H・16H
None monitor (Monitor value is 0) None monitor (Monitor value is 0)
－
17H Accumulation power supply ON time Accumulation power supply ON time 1h
18H Motor overload factor Motor overload factor 0.1%
19H Integral input power Integral input power 1kWh
1AH Integral output power Integral output power 1kWh
1BH Analog input(VIA) Analog input(VIA) 0.01%
1CH Analog input(VIB) (With sign) Analog input(VIB) (With sign) 0.01%
1DH Analog input(VIC) Analog input(VIC) 0.01%
1EH・1FH
None monitor (Monitor value is 0) None monitor (Monitor value is 0)
－
21H Torque current (With sign) Torque current (With sign) 0.1%
22H None monitor (Monitor value is 0) None monitor (Monitor value is 0)
－
23H Factory specific monitor Factory specific monitor ―
24H PID feedback value PID feedback value 0.01Hz

Toshiba TOSVERT VF-S15 series Specifications

General

Series	VF-S15
Category	Inverter
Control Method	V/f control, Sensorless vector control
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication Options	Modbus
Braking Unit	Built-in
Power Rating	0.4 kW to 15 kW
Input Voltage	Single-phase 200 to 240V, Three-phase 200 to 240V, 380 to 480V
Cooling Method	Fan cooling
