Toshiba TOSVERT VF-S15 series Function Manual

E658130
- 1 -
Introduction
Thank you for purchasing the “CC-Link
®
option (CCL003Z)” for TOSVERT VF-S15 drive.
This option can connect with open field network CC-Link and data communications with
the CC-Link master through installing this option in the VF-S15 and using it. Besides this
instruction manual, the “CC-Link option Instruction Manual” is required to develop
software communicating with VF-S15.
This option needs the option adaptor to connect VF-S15 which type form is SBP009Z.
Please match here and buy it when SBP009Z is not at hand yet.
After reading this function manual, please keep it handy for future reference.
For details of its general handling, see an instruction manual attached with the option
unit.
- TOSVERT VF-S15 Instruction Manual ·························································· E6581611
- TOSVERT VF-MB1/S15 communication option Precautions Manual··········· E6581739
- TOSVERT VF-S15 Communication Function Instruction Manual················· E6581913
CC-Link
®
is a registered trademark of Mitsubishi Electric Corporation.

Toshiba TOSVERT VF-S15 series Specifications

General

Series	VF-S15
Category	Inverter
Control Method	V/f control, Sensorless vector control
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication Options	Modbus
Braking Unit	Built-in
Power Rating	0.4 kW to 15 kW
Input Voltage	Single-phase 200 to 240V, Three-phase 200 to 240V, 380 to 480V
Cooling Method	Fan cooling
