E658130
- 22 -
■Input function selection from the CC-Link.
The function numbers selection of the RYn2 to RYn8 function valid from the command of the CC-Link are following
boldface numbers.
Positive logic Negative logic Function
Speed control PM control V/f
0 1 No function is assigned ●/● ● ●
2 3 Forward run command ●/● ● ●
4 5 Reverse run command ●/● ● ●
6 7 Standby ●/● ● ●
8 9 Reset command ●/● ● ●
10 11 Preset speed command 1 ●/● ● ●
12 13 Preset speed command 2 ●/● ● ●
14 15 Preset speed command 3 ●/● ● ●
16 17 Preset speed command 4 ●/● ● ●
18 19 Jog run mode ●/● ● ●
20 21 Emergency stop by external signal * ●/● ● ●
22 23 DC braking command ●/● ● ●
24 25 2nd acceleration/deceleration ●/● ● ●
26 27 3rd acceleration/deceleration ●/● ● ●
28 29 2nd V/F control mode switching ●/● ● ●
32 33 2nd stall prevention level ●/● ● ●
36 37 PID control prohibition ●/● ● ●
46 47 External thermal error input ●/● ● ●
48 49 Forced local from communication ●/● ● ●
50 51 Operation hold (hold of 3-wire operation) ●/● ● ●
52 53 PID integral/differential clear ●/● ● ●
54 55 PID characteristics switching ●/● ● ●
56 57 Forced run operation ●/● ● ●
58 59 Fire speed operation ●/● ● ●
60 61 Acceleration/deceleration suspend signal ●/● ● ●
62 63 Power failure synchronized signal ●/● ● ●
64 65 My function-S trigger signal ●/● ● ●
74 75 Integrating wattmeter(kWh) display clear ●/● ● ●
76 77 Trace back trigger signal ●/● ● ●
78 79
Light-load high-speed operation
prohibitive signal
●/● ● ●
80 81 Holding of RY-RC terminal output ●/● ● ●
82 83 Holding of OUT terminal output ●/● ● ●
88 89 Frequency UP ●/● ● ●
90 91 Frequency DOWN ●/● ● ●
92 93 Clear frequency UP/DOWN ●/● ● ●
96 97 Coast stop command ●/● ● ●
98 99 Forward/reverse selection ●/● ● ●
100 101 Run/Stop command ●/● ● ●
104 105 Frequency setting mode forced switching ●/● ● ●
106 107 Frequency setting mode terminal block ●/● ● ●
108 109 Command mode terminal block ●/● ● ●
110 111 Parameter editing permission ●/● ● ●
120 121 Fast stop command 1 ●/● ● ●
122 123 Fast stop command 2 ●/● ● ●
134 135 Traverse permission signal ●/● ● ●
136 137 Low voltage operation signal ●/● ● ●
140 141 Forward deceleration ●/● ● ●
142 143 Forward stop ●/● ● ●
144 145 Reverse deceleration ●/● ● ●
146 147 Reverse stop ●/● ● ●
152 153
No.2 motor switching
(AD2 + VF2 + OCS2)
●/● ● ●
200 201 Parameter editing prohibition ●/● ● ●
202 203 Parameter reading prohibition ●/● ● ●
* This function is not dependent on cmod.
