E658130
- 26 -
2. Remote register (Inverter -> Master)
RWr
Address Signal Description
RWr n Monitor value 1
When (RYnC) is on, the monitored value specified to the lower 8 bits of
the monitor code (RWwn) is set.
RWrn+1
Monitor value 2
(output frequency)
When "0" is set to the higher 8 bits of the monitor code (RWwn), the
current output frequency is always set. When other than "0" is set to the
upper 8 bits of the monitor code (RWwn) and (RYnC) is on, the
monitored value specified to the higher 8 bits of the monitor code
(RWwn) is set.
RWrn+2 Response code 1
When (RYnF) is on, the response code correspond to the instruction
code of (RWwn+2) is set. The value "0" is set for a normal reply and
other than "0" is set for data fault, mode error, etc.
RWrn+3 Read data 1
For a normal reply, the reply data to the instruction specified by the
instruction code is set.
RWrn+4 Monitor value 3
When (RYnC) is on, the monitored value specified to the monitor code
(RWw n+4) is set.
RWrn+5 Monitor value 4
When (RYnC) is on, the monitored value specified to the monitor code
(RWw n+5) is set.
RWrn+6 Monitor value 5
When (RYnC) is on, the monitored value specified to the monitor code
(RWw n+6) is set.
RWrn+7 Monitor value 6
When (RYnC) is on, the monitored value specified to the monitor code
(RWw n+7) is set.
RWrn+8
Trip information
(Trip code)
The fault data of the trip history No. specified by (RWw n+8) is stored in
the lower 8bits.
The trip history No. specified is echo backed to the upper 8bits.
RWrn+9
Trip information
(output frequency)
Output frequency of the trip history No. specified in (RWw n+8) is
stored.
RWrn+A
Trip information
(output current)
Output current of the trip history No. specified in (RWw n+8) is stored.
RWrn+B
Trip information
(output voltage)
Output voltage of the trip history No. specified in (RWw n+8) is stored.
RWrn+C
Trip information
(energization time)
Energization time of the trip history No. specified in (RWw n+8) is
stored.
RWrn+D
to
RWrn+F
Reserved
Do not use it.
RWrn+10 Reply code 2
When (RYnF) is on, the response code correspond to the instruction
code of (RWw n+10) is set. The value "0" is set for a normal reply and
other than "0" is set for data fault, mode error, etc.
RWrn+11 Read data 2
For a normal reply, the reply data to the instruction specified by the
instruction code is set.
RWrn+12 Reply code 3
When (RYnF) is on, the response code correspond to the instruction
code of (RWw n+12) is set. The value "0" is set for a normal reply and
other than "0" is set for data fault, mode error, etc.
