TRANSPORTATION AND INSTALLATION MANUAL
61
5. Installing the Controller (In case of TSL3100E)
5.1. External Dimensions
For the TSL3100, please see "4. Installation of the Controller (In case of TSL3100)." For
the TS3100, please see "6. Installation of the Controller (In case of TS3100)."
External view of the controller is shown in Fig. 5.1.
Fig. 5.1 External view of the controller (TSL3100E)
Cable clamp
Unit: mm
Robot connector dimension
