TRANSPORTATION AND INSTALLATION MANUAL
98
Connecting the Power Cable
9.1.2.
The power cable “ACIN” ([1] of Fig. 9.1) is used to supply the main AC power to the
controller.
Table 9.1 Power supply specifications (TS3100)
Power supply
Single-phase, 200~240V,
50/60H
Z
±1H
Z
Instantaneous
power failure
Within 40 msec
Grounding
Class D grounding
The connector is a standard accessory.
ACIN plug
connector
Type: 03JFAT-SAYGF-I
Maker: Japan Aviation Electronics
Industry, Limited
ACIN cable
clamp
JL04-2022CK(14)-R
Maker: Japan Aviation Electronics
Industry, Limited
Wire
3.5mm
2
~5.5mm
2
As the cable is not an accessory, use the attached plug connector connected to ACIN
on the controller side to manufacture cable.
Connect the connector and the power cable by soldering.
For the terminal arrangement, see Para. 9.1.7.
! DANGER
• Be sure to use the designated wire. Failure to do so could lead to fires or
faults.
• When connecting the connector and wires, make sure not to mistake the
terminal arrangement.
• After making the connection, use a tester, etc., to confirm the connection.
! CAUTION
• Unless the main power is normally supplied to the controller due to phase
defect or voltage drop, an error of “8–027 Slow Charge error” occurs. When
this happens, make sure that the maser power voltage at the controller
power connector satisfies the specified input power of the controller, and that
the same voltage is stabilized.
• For details on "8-027 Slow Charge error," see the "Instruction Manual:
Alarms" provided as a separate volume.
