Photocell function Safety
 Reverse at closing: an interruption of the photocell during closing makes the gate reverse (open). In automatic mode
the gate closes as soon as the pause time has run out. In impulse operation another closing command has to be
given.
 Stop after release open: an interruption of the photocell beam during opening or closing makes the motor stop as long
as the photocell stays interrupted. After release of the photocell, the gate opens. In automatic mode the gate closes as
soon as the pause time has run out, in impulse operation another closing command has to be given.
 Stop at closing, after release open: an interruption of the photocell during closing makes the motor stop as long as
the photocell stays interrupted. After release of the photocell, the gate opens.
Photocell with pause time Safety
 no inuence: the photocell doesn’t have any inuence on the pause time in automatic mode.
 Immediate closing: in automatic mode an interruption of the photocell during pause time shortens the pause time.
After release of the photocell the gate starts closing.
 Restart pause time: in automatic mode an interruption of the outer photocell during pause time, restarts the pause
time. As soon as the pause time has run out, the gate closes.
 Close after opening: If the photocell is interrupted during the opening movement, the gate starts closing as soon as
it reached end position open after release of the photocell.
Photocell test Safety
 active: photocell self-test is executed with an opening impulse (switch, button) in gate position „closed“.
 not active: photocell self-test is not executed.
Attention
• The photocell self-test can only be deactivated by selecting „not active“.
• The deactivation of the self-test function is only permitted if the safety installations correspond to the
category 3 !
