- 20 - tousek / E_PULL-T5-T8-T10_49002305 / 19. 12. 2013
Function
K1 K2
Gate status display
1
Gate in CLOSE-Position 1 0
Gate in OPEN-Position 0 1
2
Gate in CLOSE-Position 0 0
Gate opens or closes 0 1
Gate stopped or fault
(Gate not in end position)
1 0
Gate in OPEN-position 1 1
0 = signal contact open, 1= signal contact closed
• You will need for use of adjustments one of the selected adjustements (courtyard-/control l hence
gate status 1 or 2.
Signal lamp
• a signal lamp can be con-
nected to the terminals 10/11
(230V, max. 100W).
Pre-alert OPEN (Signal lamp:terminals 10/11) Light / Lamps
turned off
1–30s adjustable: Before each opening movement the
signal lamp/ ashing light is activated for the adjusted
time.
Pre-alert CLOSE (Signal lamp: terminals 10/11)
turned off
1–30s adjustable: Before each closing movement the
signal lamp/ ashing light is activated for the adjusted time.
The following two menu points can only be selected if the menu point additional menu is adjusted to „Courtyard-/Control
lamp“ (hence shown on display).
Courtyard lamp (Description add. modules page 21) Light / Lamps
turned off
5–950 adjustable: at the courtyard lamp output an external lamp can be connected (e.g. garden lamp), which can be
turned on for each opening command for the duration of adjusted time.
Pilot (control) lamp (Description add. modules page 21) Light / Lamps
llluminates at opening/closing: The pilot lamp output is activated during opening- and closing movement.
Flashing/illuminates/ashing rapidly: The pilot lamp output is activated as follows: During opening the pilot lamp
ashes slowly. During pause time, in opened position or when the gate stops it is illuminated. During the closing
movement it ashes rapidly. If the gate is closed, the pilot lamp expires
Illuminated when gate is open: Pilot lamp is illuminated as soon as the gate has reached end position open.
Additional module (Description add. modules page 21) Light / Lamps
Courtyard lamp/control lamp: the menu points courtyard lamp and control lamp are ready for adjustmenticht and Control
lamp zur Einstellung bereit (that means if not selected, these menu points will not be shown on the display)
Gate status 1: with the two potential-free signal
contacts K1 and K2, the gate end positions (limits) can be
evaluated.
Gate status 2: with the two potential-free signal contacts
K1 and K2, the gate end positions (limits), the gate move-
ment as well as a gate stop outside of the end positions
can be evaluated.
11
10
N
L
Light / Lamps Connections and adjustments
Warning
• Before connection works please turn off the main power switch !
• Safety rules please see page 12 !
