Note: The factory settings of the
single menu points are marked
with in this manual.
The mechanical stops have to be placed so
that possibly existing safety contact edges
can not be triggered, as this would lead to
an error message.
Status display Diagnosis
Status display for inputs as photocell, safety sensing edges, stop button, impulse switch ....
I Impulstaster
P pedestrian entry
C CLOSE-button
S STOP-button
Ph photocell contact
ME main safety edge
SE side safety edge
Delete positions Diagnosis
NO: does not delete the end positions “gate closed”
and “gate open”
YES: the determined end positions are beeing deleted.
Note: the end positions will be determined after new impulse.
Factory setting Diagnosis
NO: no reset back to factory settings
YES: reset back to factory settings
Software version Diagnosis
shows the software version on display
Serial number Diagnosis
shows der Seriennummer am Textdisplay
Protocole Diagnosis
shows the protocole list on display: all events that take place are protocolled in this list.
with the buttons + and - the single events can be seen:
Status Sensor Diagnosis
Degree and signal strenght of rotation speed sensor is shown on display.
All inputs okay. Impulse switch, pedestrian opening button and clos-
ing button okay. Stop-button and photocell not ok.
Main sensing edge interrupted. Side closing edge not
okay or triggered.
status: okay
status: not okay or triggered
status: safety sensing edge interrupted
for example
Diagnosis Connections and adjustments
$$$$$$$$$$$$$$$$
$$$$$$$$$$$$$$$$
I G Z S LS HK NK
$$$$$$$$$$$$$$$$
$$$$$$$$$$$$$$$$
I G Z S LS HK NK
$$$$$$$$$$$$$$$$
$$$$$$$$$$$$$$$$
T -00 00:00:00.0
Event
With
*
the protocole beginning
hence the end is shown
Type of event
Time since the last event:
DAYS HOURS : MINUTES : SECONDS
