- 18 - tousek / E_PULL-T5-T8-T10_49002305 / 19. 12. 2013
Attention
With force adjustment the valid safety regulations and standards have to be strictly followed !
Max. force 70% (factory setting) Motor
25–100% adjustable [increment 5]: determines the max. possible motor force.
ARS response time 0,50s (factory setting) Motor
0,15–0,95s adjustable [increment 0,05]: determines, in which time the AR-System responds. The lower the value,
the more sensitive the sensor will react.
Speed 100% (factory setting) Motor
65–100% adjustable [increment 5]: determines the speed of motor.
Soft stop distance 0,5m (factory setting) Motor
0–2m adjustable [increment 0,1]: determines the distance of soft run.
Soft stop speed 50% (factory setting) Motor
30–60% adjustable [increment 5]: determines the speed during soft run.
End position OPEN -5 (factory setting) Motor
0...-30 adjustable [increment 1]: for readjustment of the automatically detected OPEN limit position of gate (e.g. for
safety sensing barriers). With adjustment 0 the motor runs to the previously learned open position.
For a diminished drive distance the value can be extended to up to -30.
This adjustment is ONLY adopted in CLOSED-position.
End position CLOSE -5 (factory setting) Motor
0...-30 adjustable [increment 1]: for readjustment of the automatically detected CLOSE limit position of gate (e.g.
for safety sensing barriers). With adjustment 0 the motor runs to the previously learned close position.
For a diminished drive distance the value can be extended to up to -30.
This adjustment is ONLY adopted in CLOSED-position.
Motor Connections and adjustments
