9
Chapter 1
Introduction
On/Off Button
Press to turn the Smart Router ON or OFF.
USB 2.0 Port
Connect a USB 2.0 storage device or a USB 2.0 printer for file or printer sharing.
USB 3.0 Port
Connect a USB 3.0 storage device or a USB 3.0 printer for content sharing, printer
sharing, or media streaming. This port is also compatible with USB 2.0 devices.
Internet Port
Connect your broadband DSL/Cable Modem to this port using an Ethernet cable.
Gigabit Ethernet 1-4 Ports
Connect Ethernet devices such as computers, game consoles, smart TVs or other
devices that require a wired connection to the internet.
Reset Button
Press and hold for about 10 seconds or until the confirmation window appears
on the touch screen, then release the button and click Ye s to start resetting your
router.
5
6
7
8
9
10
