79
Chapter 5
Congure the Router in WISP Mode
router’s IP which sends out data. In the example, the data packets will be sent to
the LAN port of Router B and then to the Server, so the default gateway should
be 192.168.0.2.
• Interface: Determined by the port (WAN/LAN) that sends out data packets. In
the example, the data are sent to the gateway through the LAN port of Router
A, so LAN should be selected.
• Description: Enter a description for this static routing entry.
5. Click SAVE.
6. Check the Routing Table below. If you can find the entry you’ve set, the static routing
is set successfully.
5. 3. Wireless
5. 3. 1. Wireless Settings
1. Visit http://tplinkwifi.net, and log in with the password you set for the router.
2. Go to Advanced > Wireless > Wireless Settings.
3. Configure the wireless settings for the wireless network and click SAVE.
• 2.4GHz - Select this checkbox to enable the 2.4GHz wireless network.
• Network Name (SSID) - Enter a value of up to 32 characters. The same Name (SSID)
must be assigned to all wireless devices in your network.
• Hide SSID - Select this checkbox if you want to hide the 2.4GHz network name (SSID)
from the Wi-Fi network list. In this case, you need to manually join the network.
